MÔ TẢ SẢN PHẨM
Module for pneumatic gages Millimar N 1701 PM-10000
- Flexibly configurable RS485 bus modules
- Powerful connection modules for evaluating measuring sensors (inductive/pneumatic)
- Synchronous data retrieval from multiple connected measuring sensors
- Ability to connect the N 1700 modules to the smart and universally applicable Millimar Cockpit Software
- Flexible and modular product combinations to tackle customer-specific measuring tasks
- Maximum theoretical bus data rate of 4189 values/s (depending on the number of connected channels)
Product information
- Flexibly configurable RS485 bus modules
- Powerful connection modules for evaluating measuring sensors (inductive/pneumatic)
- Synchronous data retrieval from multiple connected measuring sensors
- Connection of N 1700 modules via USB interface to the smart, universal evaluation and configuration software Millimar Cockpit
- Flexible and modular product combinations to tackle customer-specific measuring tasks
- Maximum theoretical bus data rate of 4189 values/s (depending on the number of connected channels)
| Millimar N 1701 PM-10000 | Art. no. 5331152 | |
|---|---|
| Product type | N 1701 PM-10000 |
| Current consumption | 32 mA |
| Measuring span µm | 25 µm |
| Resolution µm | 0,1 |
| Compatibility | Mahr |
| Configuration | Millimar Cockpit Software |
| Zero setter | Electrical |
| Data transmission rate | 4189 Hz |
| Error limit | ± 0.8 µm in the range ± 38 µm and ± 0.5 µm in the range ± 25 µm |
| Data interface | RS-485 |
| Energy supply | + 5V from N 1700 Bus |
| Operating temperature from | 0 °C |
| Operating temperature up to | 40 °C |
